Sulphuric Acid Pump

ackaging & Delivery

Packaging Detail: By Wooden Case

Delivery Detail: 10 days

Specifications

LSB Sulphuric Acid Pump

To pump acid and alkali

Cast iron lined by PTFE

Temperature: less than 150 C

Good Performace



LSB Model Sulphuric Acid Pump



Description





LSB Fluoroplastic-lined chemical pump is developed according to international standard. The pump casing is made of cast steel lined with PTFE (F46); cover, impeller and shaft sleeve are made of metal wrapped by PTFE (F46). We use the bellow type mechanical seal as the shaft seal, with 99% alumina ceramics(or silicon nitride) stator and PTFE-packing rotator, to achieve good corrosive-resistant and seal. It has several advantages of strong mechanical robustness, hard aging, no toxin broken up, and strong corrosion resistance. It can deliver any concentrate organic acid, inorganic acid, or both mixed.





Sulphuric Acid Pump Specifications:



1. Flow rate up to 200m3/h

2. Delivery head up to 40.0m

3. Power up to 30.0 kw     2900/1450 r/min

4. Suitable Medium:Acid,Alkali,Oxidant and other kinds of , IN EVERY CONCENTRATION.

5. Suitalbe Temp:-50°C~+150°C

6. Mechanical Seal

Sulfuric acid pump pictures:



Technical Parameters

型号	转速 n=2900 r/min					转速 n=1450 r/min
	流量 (m³/h)	扬程 m	电机功率 Kw	汽蚀余量(m)	效率(%)	流量m³/h	扬程 m	电机功率 Kw	汽蚀余量(m)	效率(%)
LSB40-32-125	6.3	20	1.5	3.0	36	3.2	5	0.55	3.0	52
LSB40-32-160	6.3	32	3	3.0	31	3.2	8	0.75	3.0	47
LSB40-32-200	6.3	50	7.5	3.0	23	3.2	12	1.1	3.0	40
LSB40-32-250	6.3	80	11	3.0	24	3.2	20	1.5	3.0	24
LSB50-32-125	12.5	20	2.2	3.0	51	6.3	5	0.55	3.0	52
LSB50-32-160	12.5	32	4	3.0	46	6.3	8	0.55	3.0	47
LSB50-32-200	12.5	50	7.5	3.0	39	6.3	12.5	1.1	3.0	40
LSB65-50-125	25	20	3	3.5	62	12.5	5	0.55	3.5	55
LSB65-50-160	25	32	5.5	3.5	57	12.5	8	1.1	3.5	51
LSB65-40-200	25	50	11	3.5	52	12.5	12.5	1.5	3.5	46
LSB65-40-250	25	80	18.5	3.5	50	12.5	20	3	3.5	43
LSB80-65-125	50	20	5.5	4.0	69	25	5	1.1	4.0	64
LSB80-65-160	50	32	11	4.0	67	25	8	1.5	4.0	62
LSB80-50-200	50	50	15	4.0	63	25	12.5	2.2	4.0	57
LSB80-50-250	50	80	30	4.0	66	25	20	5.5	4.0	51
LSB100-80-125	100	20	11	4.5	77	50	5	1.5	4.5	74
LSB100-80-160	100	32	15	4.5	73	50	8	2.2	4.5	69
LSB100-65-200	100	50	30	4.5	73	50	12.5	5.5	4.5	68
LSB125-80-160	160	32	30	5.0	70	80	8	5.5	5.0	74
LSB125-100-200	250	50	55	5.0	65	100	12.5	11	5.0	71
LSB125-100-280	200	100	90	5.0	73	100	25	15	5.0	73
