Heat-conducting Oil Pump

Product Name：RY Series air-cooled heat conducting oil pump
Manufacturer：Boutou Haina Pump

RY Series heat conducting oil pump
Abstract:
heat-conducting oil pump performance range (according to design points) 1, flow:1-500m3 / h; 2,:head 10-125m; 3,:-20. C-350℃;



● Overview
 RY Series air-cooled heat conducting oil pump reasonable structure, excellent performance, reliable quality. For delivery of solid particles of high-temperature liquid. RY Series air-cooled heat conducting oil pump and corrosion-resistant contact with the medium temperature depends on the major parts of the material (divided into three categories: 1.HT200; II.ZG230-450; III.1Cr18Ni9Ti, OCr18Ni12-Mo2Ti)


● advantages and characteristics of
RY Series air-cooled heat conducting oil pump with advanced technology, high efficiency, in the long-term stability under hot running no leakage, no additional cooling system, the use of safe and reliable, in our heat carrier heating system has been widely used, has entered the petroleum, chemical, rubber, plastics, pharmaceutical, textile, printing and dyeing, road construction, food and other industries, RY Series air-cooled heat conducting oil pump is mainly used for delivery of solid particles of the weak high-temperature corrosion of liquid, temperature ≤ 370 ℃, is an ideal circulation pump. The HTF pump widely used paper lunch boxes high temperature setting, dynamically vulcanized tire and rubber recycling machinery, vulcanizing, rubber, drying, feed drying, dyeing and printing, chemicals, plywood production, membrane production, asphalt heating, drying noodles industry. (1) RY series air-cooled heat conducting oil pump is the digestion and absorption of foreign oil pump developed on the basis of the second generation, the basic structure for the single-stage single-suction cantilever leg support structure, heat pump axial suction imports, exports Center vertically upward, and motor mounted on the base with. (2) RY-type support for conducting oil pump with a double-ended ball bearing support structure, front-end use lubricating oil, the back-end using grease lubrication, the middle of a lead pipe to observe seals and recycling at HTF. (3) RY Series air-cooled heat conducting oil pump uses heat from the thermal structure, changing the traditional water-cooling structure, the simple structure, small size, operating cost savings, performance, use and reliable. (4) RY series air-cooled heat conducting oil pump seal packing seal and mechanical combination in the form of packing filler with high temperature, good thermal adaptation, and mechanical seal is a high mechanical strength, wear resistance good carbide materials, to ensure the sealing performance under high temperature conditions. (5) RY series air-cooled heat conducting oil pump using third-generation polytetrafluoroethylene (referred to as PTFE) to do lip seal, the sealing performance of a leap than the rubber seal reliability by 25 times, strong corrosion resistance.
● RY Series air-cooled heat conducting oil pump performance range (by design point)
 1, flow 1-500m3 / h; 2, head 10-125m; 3, -20. C-350. C;
Example:Heat-conducting Oil Pump 50-32-160(Entrance diameter:50mm;;;;Outlet diameter:32mm)

Model	Capacity m 3 /h	Lift m	Speed r/min	Power kw		Efficiency η%	Heat-conducting Oil Pump with Motor-Y
				Shaft power	Power Distribution
15-15-100	3	10	2800	0.45	0.75	20	801
15-15-100A	2	10	2800	0.36	0.55	18	AO2-7122
15-15-100B	1	10	2800	0.2	0.37	15	AO2-7112
20-20-100	1	10	2800	0.09	0.37	26	AO2-7112
20-20-125	1.5	22	2800	0.22	0.75	30	801
40-25-160	10	28	2900	1.72	2.2	45	90L
25-25-160	3	27	2900	0.53	1.5	30	90S
32-32-160	6	28	2900	0.85	1.5	50	90S
50-32-160	12.5	30	2900	1.90	3.0	57	100L
50-32-200	18	40	2900	3.92	5.5	50	132Sl
50-32-200A	16	32	2900	3.35	4	42	112M
50-32-250	12.5	80	2900	6.2	11	44	160Ml
65-50-160	20	32	2900	3.17	5.5	55	132S1
65-40-200	30	48	2900	6.3	7.5	62	132S2
65-40-200A	25	35	2900	4.0	5.5	59	132S1
65-40-250	25	80	2900	10.3	15	53	160M2
65-40-250A	20	51	2900	5.67	7.5	49	132S2
65-40-315	25	125	2900	18.9	30	45	200L1
65-40-315A	22.5	100	2900	15.3	22	40	180M
80-50-200	50	50	2900	9.7	15	70	160M2
80-50-200A	45	40	2900	7.8	11	63	160M1
80-50-200B	40	32	2900	6.37	7.5	55	132S2
80-50-250	50	80	2900	17.1	22	58	180M
80-50-250A	43	60	2900	12.8	15	55	160M2
80-50-315	50	125	2900	30.4	45	56	225M
80-50-315A	45	100	2900	23.6	30	52	200L1
100-65-200	100	50	2900	18.4	22	74	180M
100-65-200A	94	44	2900	16	22	70	180M
100-65-200B	87	38	2900	13.8	15	65	160M2
100-65-200C	80	32	2900	11.8	15	59	160M2
100-65-250	100	80	2900	32.06	37	68	200L2
100-65-250A	95	72	2900	29	37	64	200L2
100-65-250B	90	65	2900	26.2	30	61	200L1
100-65-250C	85	50	2900	20.3	30	57	200L1
100-65-315	100	125	2900	50.06	75	68	280S
100-65-315A	95	113	2900	45.23	55	64.63	250M
100-65-315B	90	100	2900	40.5	55	60.50	250M
100-65-315C	82	84	2900	34.76	45	54	225M
125-100-200	200	50	2900	35.4	45	77	225M
125-100-200A	178	40	2900	26.6	37	73	200L2
125-100-250	200	70	2900	47	55	80	250M
125-100-250A	190	63	2900	41.6	55	78	250M
125-100-250B	180	57	2900	37.9	45	74	225M
125-100-250C	170	51	2900	32.15	45	72	225M
125-100-250D	150	70	2900	40	45	70	225M
150-150-200	350	50	2900	60	75	80	280S
150-150-200A	313	40	2900	45	55	76	250M
200-150-400	350	50	1450	61.8	75	78	280S
200-150-400A	330	45	1450	52.8	75	77	280S
250-200-400	500	50	1480	86.2	110	79	315S
250-200-500	500	80	1480	136	160	76.5	315M
250-200-500A	400	50	1480	75	90	73	280M

Summarize:
RY series heat conducting oil pump draws in China and abroad all kinds of advanced thermal characteristics of the oil circulating pump.  It is used widely in heating medium carrier system and has the typical of reasonable structure, advanced technology, high efficiency, and long-term stable operation without leakage in the hot state, no additional cooling system but safe and reliable. It has entered the petroleum, chemical, rubber, plastics, pharmaceuticals, weaving printing and dyeing, construction, food and other various industrial fields, mainly used for transporting the weak high-temperature corrosive liquid without the solid particles, the usage of temperature ≤ 350oC, and it is an ideal hot oil circulation pump.
2. Usage:
RY-type heat-conducting oil pump can be widely used in petroleum, grease, boilers, construction, road maintenance, pharmaceutical, plastics, rubber, containing fibroblasts, textile, printing and dyeing, food and other industrial areas, it is an ideal medium heat carrier circulating pump,
3. Characteristic
The product has a typical of reasonable structure, advanced technology, high efficiency, and long-term stable operation without leakage in the hot state, no additional cooling system but safe and reliable.
Flux 4.5 ~ 400m3 / h  outlet pressure 15 ~ 85m, rotate speed 2900r/min
